Build your own simple old school cathode ray tube oscilloscope, Lissajous display, or a retro tube scope clock with this simple CRT driver board. The board is designed to work with various 1 to 3 inch diameter electrostatic CRTs and works well with the Dutchtronix scope clock kit. The board contains the necessary power supply circuits to generate the required high voltages for the CRT and includes 3 simple controls for focus, astigmatism, and brightness. Deflection amplifiers on the board amplifies ±5V single ended input signals to differential deflection voltages with straight-forward controls for gain and position. The solid-state design is documented. This PCB design is also featured in the September 2014 QST magazine article 'A New Life for an SB-610 Monitor Scope' by Dave Cook, WA0TTN. Input sensitivity level for X and Y inputs with circuit operating at maximum gain (XSIZE and YSIZE set to max) has been characterized to be 100-140mVpp per inch on a 3BP1 CRT with a deflection voltage differential of 60-85Vpp, so the overall gain is ~600. Propellerhead Reason 7 Crack Download.
